Intel CPU Core Ultra 7 270K Plus Tray

Specifications:

Product Number: AT807683B9B4884

Essentials

• Product Collection: Intel® Core™ Ultra Processors (Series 2)

• Code Name: Products formerly Arrow Lake

• Vertical Segment: Desktop

• Processor Number: 270K PLUS

• Overall Peak TOPS (Int8): 36

CPU Specifications

• Total Cores: 24

• # of Performance-cores: 8

• # of Efficient-cores: 16

• # of Low Power Efficient-cores: 0

• Total Threads: 24

• Max Turbo Frequency: 5.5 GHz

• Intel® Turbo Boost Max Technology 3.0 Frequency ‡: 5.5 GHz

• Performance-core Max Turbo Frequency: 5.4 GHz

• Efficient-core Max Turbo Frequency: 4.7 GHz

• Performance-core Base Frequency: 3.7 GHz

• Efficient-core Base Frequency: 3.2 GHz

• Cache: 36 MB Intel® Smart Cache

• Total L2 Cache: 40 MB

• Processor Base Power: 125 W

• Maximum Turbo Power: 250 W

• Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes

• AI Software Frameworks Supported by CPU:

  • OpenVINO™
  • WindowsML
  • DirectML
  • ONNX RT
  • WebNN

• CPU Lithography: TSMC N3B

Memory Specifications

• Max Memory Size (dependent on memory type): 256 GB

• Memory Types: Up To DDR5 7200 MT/s

• Max # of Memory Channels: 2

• ECC Memory Supported ‡: Yes

GPU Specifications

• GPU Name‡: Intel® Graphics

• Graphics Base Frequency: 300 MHz

• Graphics Max Dynamic Frequency: 2 GHz

• GPU Peak TOPS (Int8): 8

• Graphics Output:

  • eDP1.4b
  • DP 2.1 UHBR20
  • HDMI 2.1 FRL

• Xe-cores: 4

• Max Resolution (HDMI)‡:
  • 4096 x 2304 @ 60Hz (HDMI 2.1 TMDS)

  • 7680 x 4320 @ 60Hz (HDMI 2.1 FRL)

• Max Resolution (DP)‡: 7680 x 4320 @ 60Hz

• Max Resolution (eDP - Integrated Flat Panel)‡: 3840 x 2400 @ 120Hz

• DirectX* Support: 12

• OpenGL* Support: 4.5

• OpenCL* Support: 3

• H.264 Hardware Encode/Decode: Yes

• H.265 (HEVC) Hardware Encode/Decode: Yes

• AV1 Encode/Decode: Yes

• Intel® Quick Sync Video: Yes

• # of Displays Supported ‡: 4

• Device ID: 0x7D67

• Intel® Deep Learning Boost (Intel® DL Boost) on GPU: Yes

• AI Software Frameworks Supported by GPU:

  • OpenVINO™
  • WindowsML
  • DirectML
  • ONNX RT
  • WebGPU

NPU Specifications

• NPU Name‡: Intel® AI Boost

• NPU Peak TOPS (Int8): 13

• Sparsity Support: Yes

• Windows Studio Effects Support: Yes

• AI Software Frameworks Supported by NPU:

  • OpenVINO™
  • WindowsML
  • DirectML
  • ONNX RT
  • WebNN

Expansion Options

• Direct Media Interface (DMI) Revision: 4

• Max # of DMI Lanes: 8

• Intel® Thunderbolt™ 4: Yes

• Scalability: 1S Only

• PCI Express Revision: 5.0 and 4.0

• PCI Express Configurations ‡ Up to:
  • 1x16+2x4
  • 2x8+2x4
  • 1x8+4x4

• Max # of PCI Express Lanes: 24

Package Specifications

• Sockets Supported: FCLGA1851

• Thermal Solution Specification: PCG 2020A

• Max Operating Temperature: 105 °C

• Package Size: 45 mm x 37.5 mm

Advanced Technologies

• Intel® Gaussian & Neural Accelerator: 3.5

• Intel® Thread Director: Yes

• Intel® Speed Shift Technology: Yes

• Intel® Turbo Boost Max Technology 3.0 ‡: Yes

• Intel® Turbo Boost Technology ‡: 2.0

• Intel® Hyper-Threading Technology ‡: No

• Intel® 64 ‡: Yes

• Instruction Set: 64-bit

• Instruction Set Extensions:
  • Intel® SSE4.1
  • Intel® SSE4.2
  • Intel® AVX2

• Idle States: Yes

• Enhanced Intel SpeedStep® Technology: Yes

• Thermal Monitoring Technologies: Yes

• Intel® Volume Management Device (VMD): Yes
