Chieftec Power Supply PowerPlay Series GPU-1050FC 1050W

Specifications:

• Product Number: GPU-1050FC


Power

• Total power: 1050 W

• AC input voltage: 100-240 V

• AC input frequency: 47-63 Hz

• Input current: 13 A

• Power factor: 0.9

• Power factor correction filter (PFC): Active

• Combined current (+3.3V): 120 W

• Combined current (+12V): 999.96 W

• Combined current (+5V): 120 W

• Combined current (-12V): 3.6 W

• Combined current (+5Vsb):15 W

• Max. output current (+3.3V): 22 A

• Max. output current (+12V): 83.33 A

• Max output current (+5V): 22 A

• Max. output current (-12V): 0.3 A

• Max. output current (+5Vsb): 3 A

• Energy protection properties: Overcurrent, overload, overvoltage, overheating, short circuit

Connections & interfaces

• Motherboard connector: 20+4 pin ATX

• Power cable length motherboard: 60 cm

• Number of SATA power connectors: 9

• SATA power cable length: 150, 800 mm

• Number of Molex connectors 4-pin: 3

• Peripheral (Molex) power cable length: 150, 700 mm

• EPS power connector (8-pin): Yes

• Number of PCI Express power connectors 6+2pin: 8

• PCI Express power cable length: 60 cm
• CPU connector (4+4 pin): Yes

• ATX power connector (20+4 pin): Yes

• Floppy drive power connection: 1

• Floppy drive connector: Yes

• PCI Express connector: Yes

• Cable type: Fully modular

Services

• 80 Plus certification: 80 PLUS Platinum

• Power supply unit (PSU) form factor: PS/2
• ATX version: 2.3


Design

• Product color: Black, Red

• cooling: Active

• Fan diameter: 14 cm

• Number of fans: 1 fan

• Fan placement: Above

• On/off switch: Yes


Dimensions

• Width: 150 mm

• Depth: 160 mm

• Height: 86 mm
• Weight: 3.46 kg
