TP-Link Whole Home Mesh W-Fi System Deco E4 (2 Pack)

Specifications:

• Product number: Deco E4 (2 Pack)

Wireless

• Standards and Protocols Wi-Fi 5:

  • IEEE 802.11ac/n/a 5 GHz

  • IEEE 802.11n/b/g 2.4 GHz

• WiFi Speeds AC1200:

  • 5 GHz: 867 Mbps (802.11ac)

  • 2.4 GHz: 300 Mbps (802.11n)

• WiFi Range: 3-4 Bedroom Houses (3-pack)

• TP-Link Mesh Technology

• Optional Ethernet backhaul work together to link Deco units to provide seamless coverage
• 2× Antennas (Internal)
• Beamforming
• WiFi Capacity: Medium, Dual-Band, MU-MIMO
• Working Modes: Router Mode, Access Point Mode

Security

• Network Security: SPI Firewall, Access Control

• Guest Network: 1× 5 GHz Guest Network, 1× 2.4 GHz Guest Network

• WiFi Encryption: WPA-Personal, WPA2-Personal

Hardware

• Ethernet Ports: 2× 10/100 Mbps Ports
• Per Deco Unit: Supports WAN/LAN auto-sensing

• Buttons: Reset Button

Software

• Protocols: IPv4, IPv6

• Parental Controls: URL Filtering, Time Controls

• WAN Types: Dynamic IP, Static IP, PPPoE, PPTP, L2TP

• Quality of Service: QoS by Device

• Cloud Service: OTA Firmware Upgrade, TP-Link ID, DDNS

• NAT Forwarding: Port Forwarding, UPnP

• IPTV: IGMP Proxy, IGMP Snooping, Bridge, Tag VLAN

• DHCP: Address Reservation, DHCP Client List, Server

• DDNS: TP-Link

• Management Features: Deco App

Other

• Network Services Enabled by Default: Web Server

• Manage and configure device through web (HTTP/HTTPS): Port: 80/443, Protocol: TCP

• DNS: Port: 53, Protocol: TCP & UDP

• DHCP Server: IP address assignment (DHCP), Port: 67, Protocol: UDP

• App management: Manage and configure device through app

Test Data

• WiFi Transmission Power
• CE:

  • <20 dBm (2.4 GHz)

  • <23 dBm (5 GHz)

• FCC:

  • <30 dBm

Physical

• Dimensions (W×D×H): 90.7 × 90.7 × 190 mm
• Package Contents: Deco E4 (2-pack), 2 Deco E4R Units, 1 RJ45 Ethernet Cable, 2 Power Adapters,1 Quick Installation Guide

Others

• System Requirements: Android 5.0 or later, iOS 9.0 or later

• Certifications: CE, FCC, IC, NCC, BSMI, IDA, RCM, JPA, JRF, VCCI, KC, RoHS

• Environment:
  • Operating Temperature: 0℃~40℃ (32℉ ~104℉)

  • Storage Temperature: -40℃~70℃ (-40℉ ~158℉)

  • Operating Humidity: 10%~90% non-condensing

  • Storage Humidity: 5%~90% non-condensing
